Neuro Attachment

Product Description

Neuro Attachment offered, is created specifically for orthopedic surgeries. It is designed specifically for the use of intraoperative X-ray photos and image intensifiers. A pelvic support plate is placed on top of the frame and is made with an asymmetrical structure. It's easily collapsible and just takes up a minimal amount of storage space. Neuro Attachment with traction shoe with metallic sole give a strong grip at the ankle joint, even for high traction forces. The patient's legs are supported by padded orthopedic knee crutches.

Neuro Attachment

• Extremely durable and rigid construction from aluminium alloy.
• Image fixing system with pins and completely adjustable skull clumps
• Adjustment mechanism from 4 different points.
• Easily mountable horse shoe head rest accessories.

Technical Specification

• Length of Table 1910 mm
• Width of Table Top 522 mm
• Height (Min-Max.) : 750-1000 mm
• Trendelenburg (Rev.) : 25°
• Lateral Tilt ±20°
• Back Section ±60°
• Head Section ±60°
• Leg Section 0°-90°
• Floor Locking System : Manual
